JFSC-L144A Horizontal Fiber Splice Closure
Price shown is for reference only. Contact us for accurate quotation.
Product Snapshot
- Capacity
- 144 Ports
- Material
- PC
- Protection Class
- IP68
- Mounting Type
- Aerial/Duct/Underground
- Dimensions
- 460*250*200mm
- Working Temp
- -40~+65℃
- MOQ
- From 1 piece
Get Factory Pricing
Product Overview
The JFSC-L144A Horizontal Fiber Splice Closure is designed for reliable fiber optic distribution in fiber splice closure applications. Horizontal fiber splice closure, 144 cores, PC material. IP68 rated, silicone rubber seal. Aerial, duct, and direct burial. Factory direct, OEM/ODM, MOQ from 1.
The JFSC-L144A is a 144-core horizontal fiber splice closure built on a PC shell with IP68 protection, engineered for aerial, duct, and underground splicing points in FTTH and telecom networks. At 460x250x200mm it is the compact baseline unit of the 144-core horizontal family, organizing 144 splices in a reusable, easy-to-reseal enclosure.
The PC material resists impact, UV, and corrosion, protected to IP68 against dust and continuous submersion. A silicone rubber seal keeps the closure field-resealable, so technicians can reopen and re-enter it without replacing gaskets. Clean and easy-to-follow fiber routing keeps 144 cores organized and serviceable.
The closure accepts cable diameters from 7 to 22mm with 2 inlet and 2 outlet ports, and holds up to 6 splice trays of 24 cores each. At 3.1kg it is light enough for pole and aerial installation while robust for underground. It is reusable across reentries.
Features & Benefits
- Waterproof and dust-proof with IP68 level
- Clean and easy to follow fiber routing
- Easy assembly
- It is reusable
