JFSC-L144B Horizontal Fiber Splice Closure
Price shown is for reference only. Contact us for accurate quotation.
Product Snapshot
- Capacity
- 144 Ports
- Material
- PC
- Protection Class
- IP68
- Mounting Type
- Aerial/Duct/Underground
- Dimensions
- 510*250*200mm
- Working Temp
- -40~+65℃
- MOQ
- From 1 piece
Get Factory Pricing
Product Overview
The JFSC-L144B Horizontal Fiber Splice Closure is designed for reliable fiber optic distribution in fiber splice closure applications. Horizontal fiber splice closure, 144 cores with 6 ports. PC shell, IP68, field-resealable. Aerial and underground. Factory direct, OEM/ODM, MOQ from 1.
The JFSC-L144B is a 144-core horizontal fiber splice closure built on a PC shell with IP68 protection, engineered for aerial and underground splicing where more entry ports are required. At 510x250x200mm it extends the 144-core horizontal line with 3 inlet and 3 outlet ports, giving greater flexibility in cable routing at busy network nodes.
The PC shell resists impact, UV, and corrosion, protected to IP68 against dust and submersion. A silicone rubber seal keeps the closure field-resealable for repeated re-entry. Clean and easy-to-follow fiber routing organizes the 144 cores and simplifies future splicing.
With 6 splice trays of 24 cores each, the JFSC-L144B handles full 144-core density. The 3.1kg weight suits aerial and pole mounting, while the IP68 body supports underground and duct positions. The closure is reusable across multiple reentries.
Features & Benefits
- Waterproof and dust-proof with IP68 level
- Clean and easy to follow fiber routing
- Easy assembly
- It is reusable
