JFSC-L144E Horizontal Fiber Splice Closure
Price shown is for reference only. Contact us for accurate quotation.
Product Snapshot
- Capacity
- 144 Ports
- Material
- PP
- Protection Class
- IP68
- Mounting Type
- Aerial/Duct/Underground
- Dimensions
- 550*240*220mm
- Working Temp
- -40~+65℃
- MOQ
- From 1 piece
Get Factory Pricing
Product Overview
The JFSC-L144E Horizontal Fiber Splice Closure is designed for reliable fiber optic distribution in fiber splice closure applications. Horizontal fiber splice closure, 144 cores with self-adhesive rubber seal. PC, IP68. Aerial and underground. Factory direct, OEM/ODM, MOQ from 1.
The JFSC-L144E is a 144-core horizontal fiber splice closure built on a PP shell with IP68 protection, sealed with self-adhesive rubber for a strong yet re-openable splice point. At 550x240x220mm it is the largest of the 144-core horizontal line, offering 6 inlet/outlet ports for high cable count convergence in aerial and underground networks.
The PP shell resists impact, UV, and corrosion, protected to IP68 against dust and submersion. A self-adhesive rubber seal delivers a tight bond while staying removable for maintenance. With 36 cores per splice tray (up to 4 trays), it reaches 144 cores with fewer trays and simpler routing than 24-core trays.
At 2.4 to 2.5kg it is among the lightest 144-core closures, easing pole and aerial handling despite its larger port count. Cable diameters of 4 to 20mm pass through 6 ports, suiting busy junctions and FTTH distribution sections.
Features & Benefits
- Waterproof and dust-proof with IP68 level
- Clean and easy to follow fiber routing
- Easy assembly
- It is reusable
